DIMENSIONS OF CALSS 150
RAISED FACE FIGURE 8 BLANKS |
| NPS |
Inside
Diameter
B.in. |
Outside
Diameter
O.in. |
Centerline
Dimension
A.in. |
Thickness
t.in. |
Tie bar
W.in. |
| 1/2 |
0.62 |
1.75 |
2.38 |
0.12 |
1.50 |
| 3/4 |
0.82 |
2.12 |
2.75 |
0.12 |
1.50 |
| 1 |
1.05 |
2.50 |
3.12 |
0.12 |
1.50 |
| 1.1/4 |
1.66 |
2.88 |
3.50 |
0.25 |
1.50 |
| 1.1/2 |
1.90 |
3.25 |
3.88 |
0.25 |
1.50 |
| 2 |
2.38 |
4.00 |
4.75 |
0.25 |
2.00 |
| 2.1/2 |
2.88 |
4.75 |
5.50 |
0.25 |
2.00 |
| 3 |
3.50 |
5.25 |
6.00 |
0.25 |
2.50 |
| 3.1/2 |
4.00 |
6.25 |
7.00 |
0.38 |
2.50 |
| 4 |
4.50 |
6.75 |
7.50 |
0.38 |
2.50 |
| 5 |
5.66 |
7.62 |
8.50 |
0.38 |
3.00 |
| 6 |
6.62 |
8.62 |
9.50 |
0.50 |
3.00 |
| 8 |
8.62 |
10.88 |
11.75 |
0.50 |
3.00 |
| 10 |
10.75 |
13.25 |
14.25 |
0.62 |
4.00 |
| 12 |
12.75 |
16.00 |
17.00 |
0.75 |
4.00 |
| 14 |
14.00 |
17.62 |
18.75 |
0.75 |
4.25 |
| 16 |
16.00 |
20.12 |
21.25 |
0.88 |
4.25 |
| 18 |
18.00 |
21.50 |
22.75 |
1.00 |
4.50 |
| 20 |
20.00 |
23.75 |
25.00 |
1.12 |
4.75 |
| 24 |
24.00 |
28.12 |
29.50 |
1.25 |
5.50 | |
DIMENSIONS OF CALSS 300
RAISED FACE FIGURE 8 BLANKS |
| NPS |
Inside
Diameter
B.in. |
Outside
Diameter
O.in. |
Centerline
Dimension
A.in. |
Thickness
t.in. |
Tie bar
W.in. |
| 1/2 |
0.62 |
.00 |
2.62 |
0.25 |
1.50 |
| 3/4 |
0.82 |
2.50 |
3.25 |
0.25 |
1.50 |
| 1 |
1.05 |
2.75 |
3.50 |
0.25 |
1.50 |
| 1.1/4 |
1.66 |
3.12 |
3.88 |
0.25 |
1.50 |
| 1.1/2 |
1.90 |
3.62 |
4.50 |
0.25 |
2.00 |
| 2 |
2.38 |
4./uploadfile/201208/20120807200248199.jpg |
| |
| |
|
